Apex Chassis Super HD Upper Ball Joint 99-22 Ford

Built to handle the immense torque and front-end weight of Ford’s diesel-powered trucks, the Apex Chassis Super HD Lower Ball Joint is engineered for unmatched strength, precision, and long-lasting performance. Whether you are towing heavy loads or working hard in demanding conditions, this joint keeps your diesel’s front suspension stable, responsive, and reliable.

Each joint features a forged SAE 1045 solid steel housing for maximum structural integrity and a hot-forged SAE 4140 Chromoly ball stud—polished and heat-treated for superior wear resistance and load-bearing strength. The military-grade acetal bearing ensures smooth articulation under extreme stress, providing durability and precision that heavy-duty diesel applications demand.

Precision CNC machining, induction heat treatment, and an E-coated finish provide lasting corrosion resistance and exact tolerances. A pancake-style CR rubber boot protects against contaminants and retains lubrication, while the pre-threaded zerk housing allows for fast, clean servicing. With gull-wing grease grooves, pre-greased internals, and Grade 8 hardware, the Apex Super HD Lower Ball Joint delivers professional-grade reliability and performance that diesel trucks can count on.

HOUSING

• SAE 1045 Solid Steel Forged Housing: This is unequivocally the best carbon alloy steel for this application.
• Knurled Housings: The preferred design for aftermarket installations.
• CNC Machined Housing: Make our parts and bearings dimensionally perfect, eliminating any die wear issues.

BALL STUDS

• SAE 4140 hot forged Chromoly Ball Studs: For the strongest possible metallurgy.
• Induction Heat Treated Ball Studs: Provides a very precise heat treatment to the exact depth and location we want it.
• Polished Ball Studs: Are built like an anti-friction bearing with extremely precise tolerances.
• Rolled Threads: Are made by pressing the shape of the threads into the ball stud instead of cutting. This strengthens the threads instead of weakening them and allows for easy movement of hardware. This ain't no Ikea furniture!
• Step Threads: Allows for very easy movement of hardware on install and superior holding when torqued (installer choice).

BEARING DESIGN

• Military Grade Acetal Bearing: The same bearing material spec'd by the US military for Hummer ball joints. This material is dimensionally stable (doesn't expand or contract with hot or cold, water or oil absorption), can be polished smooth as steel, is anti-friction, doesn't wear itself out under load like metal on metal, and can take an absolute pounding.

BOOTS

• CR Rubber Boots: The most durable material for undercar applications. Resistant to deterioration from road level ozone, oil/gas/engine fluids, and extreme heat or cold.
• Pancake Boot

HARDWARE

• Grade 8 - Class 10.9 Hardware: Superior tensile strength.
• Castle Nut: Industry standard where high vibration loads occur.

LUBRICATION

• Pre-threaded Zerk Housing: If you have ever installed a MOOG Ball Joint without a pre-threaded zerk fitting you will understand what a simple but great feature this is. Another installer fav.
• Greaseable: Because it should be.
• Pre-Greased: Just in case you forget, we have you covered.
• Gull Winged Grease Grooves: Allows for improved lubrication disbursement around the ball stud.
• Zerk Fittings: Included for every application.
